Unitube Non-armored Cable（GYXY）
The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. Over the tube, water-blocking material is applied to keep the cable watertight. Two parallel steel wires are placed at the two sides. The cable is completed with a polyethylene (PE) sheath.
DESCRITION OF PRODUCT
Characteristics
- Good mechanical and temperature performance.
- High strength loose tube that is hydrolysis resistant.
- Special tube filling compound ensure a critical protection of fiber.
- Two parallel steel wires ensure tensile strength.
- PE sheath protects cable from ultraviolet radiation.
- Small diameter, light weight and friendly installation.
- Long delivery length.
Standards
GYXY cable complies with Standard YD/T 769-2003.
Optical Characteristics
| G.652 | G.655 | 50/125μm | 62.5/125μm | |
|---|---|---|---|---|
| Attenuation (+20°C) | ||||
| @850nm | ≤3.0 dB/km | ≤3.0 dB/km | ||
| @1300nm | ≤1.0 dB/km | ≤1.0 dB/km | ||
| @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | ||
| @1550nm | ≤0.22 dB/km | ≤0.23 dB/km | ||
| Bandwidth (Class A) | ||||
| @850nm | ≥500 MHz·km | ≥200 MHz·km | ||
| @1300nm | ≥1000 MHz·km | ≥600 MHz·km | ||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | ||
| Cable Cut-off Wavelength | ≤1260nm | ≤1480nm |
Technical Parameters
| Cable Type | Fiber Count | Cable Diameter (mm) |
Cable Weight (kg/km) |
Tensile Strength Long/Short Term (N) |
Crush Resistance Long/Short Term N/100mm |
Bending Radius Static/Dynamic (mm) |
|---|---|---|---|---|---|---|
| GYXY | 2~12 | 9.5 | 90 | 600/1500 | 300/1000 | 10D/20D |
| GYXY | 2~12 | 10.2 | 100 | 1000/3000 | 1000/3000 | 10D/20D |
