سیم فولادی GJSFJV SX's Informations
کابل فیبر نوری زرهی سیمپلکس داخلی (GJSFJV)
کابل فیبر GJSFJV، فیبرهای بافر محکم ф900μm یا ф600μm، یک لایه از سیمهای تخت فولاد ضد زنگ را پیچیده و سپس یک لایه نخ آرامید به عنوان واحد استحکام به آن اضافه میکنند و در نهایت به کابل فیبر نوری با غلاف PVC یا LSZH تبدیل میکنند.
This cable is used across different project and manufacturing stages — from network deployment to in-house cable production.
Telecom & Power Project Contractors
Reliable finished cable supply for overhead network deployment, utility communication projects, and infrastructure integration.
Optical Cable Manufacturers
Used to supplement production capacity, expand product range, or validate new cable designs before scaling.
New Entrants to Cable Manufacturing
Start with finished cable supply, then gradually move toward in-house production with equipment and raw material support.
شرح محصول
- Stainless steel wires enhance the crush resistance of the cable and anti-rodent.
- High strength aramid yarn, high performance outer sheath.
- Small bending radius, light weight, flexibility, and friendly installation.
- Good mechanical and environmental performance.
- Flame retardant outer sheath provide good safety.
- All kinds of connector.
- Fiber optic pigtails, patch cords.
- Fiber optic equipment and instrument.
- Indoor cabling, building cabling, LAN, etc.
- Long distance, outdoor/indoor cabling, trunking, etc.
- Backbone network to the equipment in the building.
- The cabling from desk or under the carpet to ceiling.
- Small bending radius, large capacity, multi user indoor installation, unit cabling, independent using, convenient connection with each end devices.
- Recommend high density wiring, small installation space and curvature.
| جی.۶۵۲ | جی.۶۵۵ | 50/125µm | 62.5/125µm | ||
|---|---|---|---|---|---|
| Attenuation (+20°C) | |||||
| @850 نانومتر | ≤3.0dB/km | ≤3.0dB/km | |||
| @1300 نانومتر | ≤1.0dB/km | ≤1.0dB/km | |||
| @1310 نانومتر | ≤0.36dB/km | ≤0.36dB/km | |||
| @1550 نانومتر | ≤0.22dB/km | ≤0.23dB/km | |||
| پهنای باند (کلاس A) | |||||
| @850 | ≥500MHZ·km | ≥200MHZ·km | |||
| @1300 | ≥1000MHZ·km | ≥600MHZ·km | |||
| دیافراگم عددی | 0.200±0.015NA | 0.275±0.015NA | |||
| طول موج قطع کابل | ≤1260nm | ≤1480nm | |||
| نوع کابل | تعداد فیبر | قطر تنگ میلیمتر |
قطر کابل میلیمتر |
وزن کابل کیلوگرم/کیلومتر |
استحکام کششی بلند مدت/کوتاه مدت N |
مقاومت در برابر خرد شدن بلند مدت/کوتاه مدت شمال/۱۰۰ متر |
شعاع خمش استاتیک/دینامیک میلیمتر |
|---|---|---|---|---|---|---|---|
| جیجیاسافجیوی | 1 | 0.6 | 2.0 | 11 | 300/750 | 200/1000 | 20D/10D |
| جیجیاسافجیوی | 1 | 0.6 | 2.2 | 12 | 300/750 | 200/1000 | 20D/10D |
| جیجیاسافجیوی | 1 | 0.6 | 2.4 | 13 | 300/750 | 200/1000 | 20D/10D |
| جیجیاسافجیوی | 1 | 0.9 | 3.0 | 15 | 300/750 | 200/1000 | 20D/10D |
اشتراک گذاری سیم فولادی GJSFJV SX با مشتریان شما
Why We Understandسیم فولادی GJSFJV SXBeyond the Product Level
Unlike suppliers who only trade finished fiber optic cables, our expertise is rooted in the optical cable manufacturing process itself.
We work closely with multiple qualified optical cable manufacturers in China, but more importantly, we are deeply involved in fiber optic cable production lines, raw materials selection, and process design.
This means we don’t just understand what a finished cable looks like — we understand how it is produced, tested, optimized, and scaled. From fiber coloring, loose tube, SZ stranding, to sheathing and quality control, we are familiar with the complete manufacturing workflow.
For our partners, this brings long-term value. You can start by sourcing finished optical cables with us, and when the time is right to build or expand your own production capacity, we are able to support you with production lines, raw materials, technical guidance, and factory planning.
We are not here for one-time transactions. Our goal is to grow together with our partners — from cable supply to manufacturing capability.
Some of Our Chinese Clients Who Bought Machine From Us
From Cable Supply toCable Manufacturing
We support your growth at every stage. Start by buying our cables, and when you’re ready, we’ll help you build your own factory.
GJSFJV SX steel wire Supply
SKD/CKD Solutions
Production Line Setup
Raw Material Supply
TypicalCooperationModels
Flexible cooperation models to match different project needs, market roles, and business growth stages.
Direct Procurement
Ideal for contractors and ISPs needing reliable cable supply for specific projects.
- Low MOQ
- تحویل سریع
- DDP Shipping Available
Distribution Partner
For local traders who want to stock and resell Hongkai cables in their region.
- Exclusive Territory
- Marketing Materials
- Volume Discounts
OEM / ODM
We manufacture cables under your brand name, meeting your specific technical specs.
- Custom Branding
- Custom Packaging
- Confidentiality
Frequently Asked Questions About Optical Cables
Common questions from contractors, cable manufacturers, and new entrants to fiber optic projects.
What types of optical cables do you supply?
We supply a wide range of optical cables including ADSS, GYTA, GYTS, FTTH drop cables, and indoor & outdoor fiber optic cables. Cable structures, fiber counts, sheath materials, and standards can be customized according to project requirements.
Do you supply finished cables only, or also production solutions?
We supply finished optical cables for immediate deployment. At the same time, our background comes from optical cable manufacturing itself. For customers planning to expand into in-house production, we also provide cable production lines, raw materials, and technical process support.
What standards do your optical cables comply with?
Our optical cables comply with international standards such as IEC 60794, ITU-T recommendations, IEEE standards, and other customer-specified technical requirements. Test reports and specifications can be provided upon request.
Can you support long-term and stable cable supply?
Yes. We work closely with multiple qualified optical cable manufacturers in China, ensuring stable production capacity, consistent quality control, flexible lead times, and long-term supply reliability for ongoing projects.
What is your minimum order quantity (MOQ)?
MOQ depends on cable type, fiber count, and customization level. For standard designs, flexible MOQs are available. Please contact us to discuss your specific requirements.
Can I start with finished cables and later move to manufacturing?
Yes. Many of our long-term partners started with finished cable purchases for market validation and project execution, and later expanded into cable manufacturing with our support in equipment selection, raw materials, and production process design.
Do you provide technical and after-sales support?
We provide technical guidance on cable selection, application scenarios, installation considerations, and quality control. For manufacturing customers, we also support production line setup, process optimization, and ongoing technical assistance.
Ready to Discuss Your Cable Project?
Whether you need finished optical cables for immediate deployment, or you are planning to move toward in-house cable manufacturing, our team can support you at every stage.
